This Abaqus DLOAD simulation is the perfect starting point if you’re new to user subroutines. Built specifically for beginners, it shows how to apply custom distributed loads — like sinusoidal or spatially varying pressure — using the DLOAD subroutine written in Fortran.
Originally created in Abaqus 2024 and fully converted to Abaqus 6.14-2, the package includes all required files: the .cae models, a clean .inp file, and a fully working Fortran code. Everything is ready-to-run, and the setup matches exactly what’s shown in the popular YouTube tutorial DLOAD Subroutine for Beginners — What I Wish I Knew Sooner.
Unlike other examples that skip over the important parts, this simulation walks you through every step — from defining the model and writing the DLOAD subroutine to compiling and validating the load distribution inside Abaqus.
✅ What You’ll Get in the Download (ZIP):
– DLOAD2024.cae – Model built in Abaqus 2024
– DLOAD_6.14.cae – Fully compatible version for Abaqus 6.14-2
– DLOAD.inp – Clean input file for direct import
– DLOAD.for – Working Fortran code for custom DLOAD
– README.txt – Clear instructions for usage and setup
🎓 Learning Outcomes:
– How to implement and compile a DLOAD subroutine in Abaqus
– Applying sinusoidal and spatial loads using Fortran
– Verifying custom pressure fields in simulation
– Understanding subroutine structure and syntax
– Editing the code for your own simulation needs
📂 How to Use:
Open CAE:
→ File → Open → DLOAD.cae
Import INP:
→ File → Import → Model → DLOAD.inp
Link Subroutine:
→ In Job settings → General → User Subroutine File → Select DLOAD1.for or DLOAD2.for
→ Submit job with user subroutine enabled
📺 Watch the Full Tutorial:
See the complete walkthrough step by step:
https://www.youtube.com/watch?v=mJzX1rVMPgo&t=359s&ab_channel=FEAMaster
☕ Support the Channel:
You’re not just downloading files — you’re helping independent FEA content grow. Thank you!
🚫 No refunds. This is a digital product. All sales are final.
